HP 255 G7

Bottom cover
Table 6-1 Spare part description and number
Description Spare part number
Bottom cover for use in models with an optical drive
●
Asteroid silver L49982-001
●
Dark ash silver L49983-001
Bottom cover for use in models without an optical drive
●
Asteroid silver L49984-001
●
Dark ash silver L49985-001
Front rubber feet:
●
Asteroid silver L20407-001
●
Dark ash silver L20406-001
Rear rubber feet:
●
Asteroid silver L20414-001
●
Dark ash silver L20413-001
1. Prepare the computer for disassembly (Preparation for disassembly on page 27).
2. Remove the optical drive (see Optical drive on page 28).
Remove the bottom cover:
1. Peel the rubber feet o the bottom of the computer (1).
2. Remove the 10 Phillips M2.5 × 9.0 screws that secure the bottom cover to the computer.
Component replacement procedures 31
