Table 2-1 Right-side components and their descriptions (continued)
Component Description
When AC power is disconnected (battery not charging):
● Blinking amber: The battery has reached a low battery level. When the
battery has reached a critical battery level, the battery light begins blinking
rapidly.
● O: The battery is not charging.
(6) Power connector Connects an AC adapter.
Left
Table 2-2 Left-side components and their descriptions
Component Description
(1) Memory card reader Reads optional memory cards that store, manage, share, or access information.
To insert a card:
1. Hold the card label-side up, with the connectors facing the computer.
2. Insert the card into the memory card reader, and then press in on the card
until it is rmly seated.
To remove a card:
▲ Pull the card out of the memory card reader.
(2) Drive light (select products
only)
● Blinking: The solid-state drive is being accessed.
(3) Power light ● On: The computer is on.
● Blinking: The computer is in the Sleep state, a power-saving state. The
computer shuts o power to the display and other components.
● O: The computer is o or in Hibernation. Hibernation is a power-saving
state that uses the least amount of power.
Left 5
