HP 340S G7 User Manual

Fingerprint reader board
Table 5-8 Fingerprint reader board description and part number
Description Spare part number
Fingerprint reader board
NOTE: The ngerprint reader board spare part kit does not include the cable. The cable is available as
spare part number L64902-001.
L89228-001
Before removing the ngerprint reader board, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 24).
2. Remove the bottom cover (see Bottom cover on page 25).
3. Remove the battery (see Battery on page 27).
Remove the ngerprint reader board:
1. Disconnect the cable from the ZIF connector on the ngerprint reader board (1).
2. Remove the Phillips M2.0 × 2.0 screw (2) that secures the ngerprint reader bracket to the computer.
3. Remove the bracket (3), and then remove the ngerprint reader board from the computer (4).
Reverse this procedure to install the ngerprint reader board.
Component replacement procedures 35

HP 340S G7 Specifications

General

Operating System	Windows 10 Home 64
Battery	3-cell, 41 Wh Li-ion
Display	14" diagonal HD (1366 x 768) or FHD (1920 x 1080), IPS, anti-glare, WLED-backlit
Graphics	Intel UHD Graphics
Weight	1.47 kg
Ports	1 x HDMI 1.4b, 1 x headphone/microphone combo
Wireless	Realtek 802.11ac (2x2) Wi-Fi and Bluetooth 5 Combo
Dimensions	32.4 x 22.5 x 1.99 cm
