Battery
Table 5-2 Battery description and part number
Description Spare part number
Battery, 3 cell, 41 Whr L11119-855
Before removing the battery, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 24).
2. Remove the bottom cover (see Bottom cover on page 25).
Remove the battery:
1. Remove the four Phillips M2.0 × 3.0 screws (1) that secure the battery to the computer.
2. Remove the battery from the computer (2).
Reverse this procedure to install the battery.
Component replacement procedures 27
