Solid-state drive

Table 5-4 Solid-state drive descriptions and part numbers

Description Spare part number

512 GB, PCIe + 32 GB Optane memory L82307-001

512 GB, PCIe, value L61960-001

256 GB, PCIe, value L61959-001

256 GB, PCIe + 16 GB Optane memory L72364-001

128 GB, SATA-3, TLC L61958-001

Before removing the solid-state drive, follow these steps:

1. Prepare the computer for disassembly (Preparation for disassembly on page 24).

2. Remove the bottom cover (see Bottom cover on page 25).

3. Remove the battery (see Battery on page 27).

Remove the solid-state drive:

▲ Remove the Phillips M2.0 × 2.5 screw (1), and then pull the drive from the socket (2).

Reverse this procedure to install the solid-state drive.

30 Chapter 5 Removal and replacement procedures for authorized service provider parts

Questions and Answers:

Need help?

Do you have a question about the HP 340S G7 and is the answer not in the manual?

HP 340S G7 Specifications

General

Operating System	Windows 10 Home 64
Battery	3-cell, 41 Wh Li-ion
Display	14" diagonal HD (1366 x 768) or FHD (1920 x 1080), IPS, anti-glare, WLED-backlit
Graphics	Intel UHD Graphics
Weight	1.47 kg
Ports	1 x HDMI 1.4b, 1 x headphone/microphone combo
Wireless	Realtek 802.11ac (2x2) Wi-Fi and Bluetooth 5 Combo
Dimensions	32.4 x 22.5 x 1.99 cm
