HP 3600 v2 Series Installation Guide

Appendix B Ports and LEDs
Ports
Console port
Every 3600 v2 switch provides one console port on the front panel.
Table 8 Console port specifications
Item Specification
Connector
type
RJ-45
Compliant
standard
EIA/TIA-232
Transmission
baud rate
9600 bps (default) to 115200 bps
Services
• Provides connection to an ASCII terminal.
• Provides connection to the serial port of a local or remote (through a pair of
modems) PC running terminal emulation program.
10/100Base-TX Ethernet port
Table 9 10/100Base-TX Ethernet port specifications
Item Specification
Connector
type
RJ-45
Interface attributes
• 10 Mbps, half duplex/full duplex
• 100Mbps, half duplex/full duplex
• MDI/MDI-X, auto-sensing
Max transmission
distance
100 m (328.1 ft)
Transmission medium Category-5 (or above) twisted pair cable
Standards IEEE 802.3u
1000Base-T Ethernet port
Table 10 1000Base-T Ethernet port specifications
Item Specification
45
