Getting Started 5
Getting Started
5
Menu Keys, Choose Boxes, Input Fields and Check Boxes
Menu Keys
The bottom of the display contains a menu of up to six items. Use the blank menu keys located below the
display to access these commands and functions.
Figure 9
Choose Box
To change the value in a Choose Box, press the CHOOS menu key, and a list of options appears. Scroll to
a new selection and press the OK menu key. You can press the CANCL menu key to return to the previous
value.
Figure 10
Input Field
To enter data in an input field, scroll to the field and either press the EDIT menu key to begin editing the
current value or begin typing a new value or expression. The value or expression you are entering will
appear at the bottom of the display, above the menu.
Figure 11
Check Box
Toggle the option in a Check Box off or on by using the CHK menu key.
Figure 12
