HP 3PAR StoreServ 7450c User Manual

Table 1 HP 3PAR StoreServ 7450 Storage Components
7450 Drive/Node Integrated Enclosure
24 Small Form-Factor (SFF) drive slotsConfiguration
2 Controller Nodes
PCIe slots (one per node) Fibre Channel HBA or iSCSI CNA
2 host FC ports
2 disk expansion SAS ports
1 1Gb Ethernet RCIP port
1 1Gb Ethernet management port
2 interconnect link ports
1 console port
3.46” (87.9mm) x 19”(483mm) x 26.6” (674.9mm)Dimensions (width x height x depth)
48.7lbs/22.1kg (no HDD); 65.5lbs/29.7kg (max)Weight
100-240 VAC 50-60HzPower
1+1 Redundant Hot Swap PCM with integrated battery
and cooling fan
112 CFMAir Flow
Front: 30” , Sides: None, Rear: 24”Service Clearances
Front: NoneCabling
Rear: Data/Power
M6710 / M6720 Drive Enclosures
2 I/O modulesConfiguration
4 SAS Ports
8 Ports
3.46” (87.9mm) x 19” (483mm) x 24.8” (630mm)M6710 Dimensions (width x height x depth)
6.89” (175mm) x 19” (483mm) x 24.9” (631.3mm)M6720 Dimensions (width x height x depth)
100-240 VAC 50-60HzPower
1+1 Redundant Hot Swap PCM with integrated cooling
fan
105 CFMM6710 Airflow
109 CFMM6720 Airflow
Front: 30” , Sides: None, Rear: 24”Service Clearances
Front: NoneCabling
Rear: Data/Power
Capacity Specifications
The following table lists system capacity and configuration details.
Storage System Specifications 11
