HP 425 Datasheet

7
Frequency band and operating
channels
Americas 2.412 - 2.462 GHz (1 - 11 channels)
5.180 - 5.320 GHz (36 - 64 channels)
5.500 - 5.700 GHz (100 - 140 (excluding 5600-5670 MHz) channels)
5.745 - 5.825 GHz (149 - 165 channels)
European Union 2.412 - 2.472 GHz (1 - 13 channels)
5.180 - 5.320 GHz (36 - 64 channels)
5.500 - 5.700 GHz (100 - 140 (excluding 5600-5650 MHz) channels)
Rest of World (Actual channels designated
by selecting country in UI)
2.412 - 2.472 GHz (1 - 13 channels)
5.180 - 5.320 GHz (36 - 64 channels)
5.500 - 5.700 GHz (100 - 140 channels)
5.745 - 5.825 GHz (149 - 165 channels)
Taiwan 2.412 - 2.462 GHz (1 - 11 channels)
5.280 - 5.320 GHz (56 - 64 channels)
5.500 - 5.700 GHz (100 - 140 (excluding 5600-5670 MHz) channels)
5.745 - 5.825 GHz (149 - 165 channels)
Japan 2.412 - 2.472 GHz (1 - 13 channels)
5.180 - 5.320 GHz (36 - 64 channels)
5.500 - 5.700 GHz (100 - 140 channels)
Israel 2.412 - 2.472 GHz (1 - 13 channels)
5.180 - 5.320 GHz (36 - 64 channels)
Radio FCC Part 15.247; FCC Part 15.407 (US); RSS-210 (Canada); EN 300 328; ARIB STD-T66; IDA Registration (Singapore); RCR STD-33; ARIB
STD-T71 (Japan); EN 301 893 (EU); KCC approval (Korea)
Safety UL 2043; UL 60950-1; IEC 60950-1; EN 60950-1; CAN/CSA-C22.2 No. 60950-1
Medical EN60601-1-2
RF Exposure FCC Bulletin OET-65C; RSS-102; CFR 47, Part 2, Subpart J; ANSI/IEEE C95.1 (99); Ministry of Health Safety Code 6; Australian Radiation
Protection Std.
Features Dual radio: IEEE 802.11a/n for high-throughput applications and IEEE 802.11b/g/n for legacy support applications
• Integrated antennas for both IEEE radios, supporting two spatial streams and 2x2 MIMO
• Four embedded antennas
• Both radios operate at full power and full performance on IEEE 802.3af PoE/Gigabit Ethernet
• External antenna, optional
Emissions
EN 55022 Class B; EN 301 489-1; EN 301 489-17; ICES-003 Class B; FCC Part 15, Class B
Notes
The HP 425 Access Point power information listed excludes the embedded antenna. Review the HP documentation for your AP to
understand the maximum output setting for your AP based on your country’s regulations
Two spatial stream AP, supporting 300 Mb/s per radio.
Maximum transmit power varies by country.
Regulatory model number: BJNGA-FB0002
Services
Refer to the HP website at hp.com/networking/services for details on the service-level descriptions and product numbers. For details about
services and response times in your area, please contact your local HP sales oce.
Radio characteristics
Notes
These radio characteristics apply to the HP 425 Access Points, including the embedded antenna. Power is limited based on country of operation.
Data sheet | HP 425 802.11n Dual Radio Access Point
Series

HP 425 Specifications

General

Device Type	Wireless Access Point
Product Name	HP 425
Maximum Data Rate	300 Mbps
Ethernet Ports	1
Wireless Protocol	802.11n
Frequency Band	2.4 GHz
Antennas	2 internal antennas
Power Source	Power over Ethernet (PoE) or External Power Adapter
Security Features	WPA, WPA2, WEP, 802.1X
