Hardware options installation 20
Removable media device option (ML150 G6
servers)
This process represents only one installation method. For instructions for installing the media device into a
specific server, see the installation sheet that ships with the server or the HP website
(http://www.hp.com/go/bizsupport
).
To install the component:
1. Power down the server (on page 7).
2. Do one of the following:
o Unlock and remove the bezel ("Remove the tower bezel (ML150 G6 servers)" on page 8).
o Extend the server from the rack.
3. Remove the access panel (on page 7).
4. Press the fan holder release tab, and then remove the fan holder.
5. Remove the bezel blank.
HP recommends that you remove all bezel blanks to facilitate drive installation.
