Hardware options installation 31
6.
Remove the expansion slot cover.
IMPORTANT: It may be necessary to remove the slot cover next to the slot in which you are
installing a board.
7. Install the expansion board.
8. Close the slot cover retainer.
9. Connect any required internal cables to the expansion board.
For more information, see the documentation that ships with the expansion board.
10. Install the access panel.
11. For ML110 G6 servers, slide the server back into the rack.
12. For ML150 G6 servers, do one of the following:
o Close or install the tower bezel, as needed.
o Slide the server back into the rack.
13. Connect any required external cables to the expansion board.
