6 HP StorageWorks Modular Smart Array 50 Storage Enclosure Maintenance and
Service Guide
System components
Item Description Spare part
number
Customer
replaceable?
1 I/O module 377231-001 Yes
2 Rear panel LED board with cable (cable*) 377235-001 Yes
3 Fan 377233-001 Yes
4 AC power supply 377230-001 Yes
5 Fan board with cable and screw (cable and screw*) 377233-001 Yes
6 Midplane and backplane 377232-001 Yes
7 Power button/LED board with cable (cable*) 377236-001 Yes
8 2-m (6.56-ft) SAS cable with 3-GB connector* 391564-001 Yes
9 4-m (13.12-ft) SAS cable with 3-GB connector* 391565-001 Yes
* Not shown
