123
5 Video Controllers
The Integrated Ultra VGA Video Controller
104h 6Ch graph 1024 x 768 16 75 60.2 80.000
105h 6Dh graph 1024 x 768 256 43 (i) 35.5 44.900
105h 6Dh graph 1024 x 768 256 60 48.4 65.000
105h 6Dh graph 1024 x 768 256 70 56.5 75.000
105h 6Dh graph 1024 x 768 256 75 60.2 80.000
106h 6Eh graph 1280 x 1024 16 45 (i) 47.7 75.000
107h 6Fh graph 1280 x 1024 256 45 (i) 47.7 37.500 x 2
107h 6Fh graph 1280 x 1024 256 60 63.7 55.000 x 2
107h 6Fh graph 1280 x 1024 256 72 77.7 65.000 x 2
107h 6Fh graph 1280 x 1024 256 75 79.5 67.500 x 2
110h 70h graph 640 x 480 32 K 60 31.5 25.175
110h 70h graph 640 x 480 32 K 72 37.5 31.500
110h 70h graph 640 x 480 32 K 75 37.5 31.500
111h 71h graph 640 x 480 64 60 31.5 25.175
111h 71h graph 640 x 480 64 72 37.5 31.500
111h 71h graph 640 x 480 64 75 37.5 31.500
112h 72h graph 640 x 480 16 M 60 31.5 25.175
112h 72h graph 640 x 480 16 M 72 37.9 31.500
112h 72h graph 640 x 480 16 M 75 37.5 31.500
113h 73h graph 800 x 600 32 K 60 37.9 40.000
113h 73h graph 800 x 600 32 K 72 48.1 50.000
113h 73h graph 800 x 600 32 K 75 46.8 49.500
114h 74h graph 800 x 600 64 60 37.9 40.000
114h 74h graph 800 x 600 64 72 48.1 50.000
114h 74h graph 800 x 600 64 75 46.8 49.500
115 75h graph 800 x 600 16 M 60 37.9 40.000
115 75h graph 800 x 600 16 M 72 48.1 50.000
115 75h graph 800 x 600 16 M 75 46.8 49.500
116 76h graph 1024 x 768 32 K 43 (i) 35 44.900
116 76h graph 1024 x 768 32 K 60 48.9 65.000
116 76h graph 1024 x 768 32 K 70 56.5 75.000
116 76h graph 1024 x 768 32 K 75 60.4 80.000
117 77h graph 1024 x 768 64 43 (i) 35 44.900
117 77h graph 1024 x 768 64 60 48.9 65.000
117 77h graph 1024 x 768 64 70 56.5 75.000
117 77h graph 1024 x 768 64 75 60.4 80.000
118 78h graph 1024 x 768 16 M 43 (i) 35.2 44.900
119 79h graph 1280 x 1024 32 K 45 (i) 48.7 75.000
11A 7A graph 1280 x 1024 64 45 (i) 48.7 75.000
VESA
Mode No.
Extended
Mode No.
Interface
Type
Resolution
No. of
Colors
Vertical
Refresh
(Hz)
Horizontal
Refresh
(kHz)
Dot Clock
(MHz)
