29
2 System Board - (SiS Chipset) (Part Number: D4051-63001)
Overview
Configuration
Supported Processor: P54CS.
Level-2 (L2) 256 KB cache sockets.
UMA Chipset from SiS consisting of three chips that interface between the
three main buses (the Host bus, the PCI bus and the ISA bus):
SiS 5511: Host/PCI bridge, L2 cache memory controller
and memory controller.
SiS 5512: PCI Local Data Buffer (Data Path).
SiS 5513: PCI/ISA bridge, plus integrated functions.
Six SIMM module sockets for Extended Data Out (EDO) Dram main
memory.
Onboard graphic controller:
SiS 6205 used in UMA mode.
NS 87308 or NS 87307: Super I/O which includes the following features:
Keyboard and mouse controller.
Floppy drive controller.
Two serial ports.
One parallel port.
Little-Ben chip is an HP designed chip that takes care of security features,
power management and some glue logic.
APM (Advanced Power Management) 1.1 power management compliant.
2 Mb Flash Memory (28F020-150) for BIOS.
