Switch cover
Description Spare part number
For use only with computer models with WLAN capability (includes wireless button and wireless light) 441623-001
For use only with computer models without WLAN capability 441624-001
Before removing the switch cover, follow these steps:
1.
Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2.
Disconnect all external devices connected to the computer.
3.
Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4.
Remove the battery (see
Battery on page 32).
Remove the switch cover:
1.
Turn the computer upside down, with the rear panel toward you.
2. Remove the seven Phillips PM2.0×9.0 screws (1) and the four Phillips PM2.0×2.0 screws (2) that
secure the switch cover to the computer.
3.
Turn the computer display-side up, with the front toward you.
4.
Open the computer as far as possible.
5.
Lift the rear edge of the switch cover and swing it forward.
Component replacement procedures 41
