Automating Measurements 3-15

Operator Interaction

Using the Analyzer's Title Feature

The analyzer has two 30-character title lines which can be entered using

the barcode reader. From the front panel, press

, or on an external

keyboard, press F9. Then use the barcode reader to scan in the

information from the DUT or use a keyboard to type in the information.

Once stored in the title line, the information will be included on hardcopy

dumps. The title lines can also be set or queried using the following SCPI

command:

DISPlay:ANNotation:TITLe[1|2]:DATA

For example:

OUTPUT @Rfna;"DISP:ANN:TITL1:DATA 'BPF-177, SN US95170001'"

and

OUTPUT @Rfna;"DISPlay:ANNotation:TITLe1:DATA?"

ENTER @Rfna;Title1$

Use the command

"DISPlay:ANNotation:TITLe[1|2] ON|OFF"

to display or hide the title. If you are using IBASIC, you can use the

INPUT statement to read in barcode or keyboard characters. For

example:

30 INPUT "Scan in the Barcode now",Dut$

40 OUTPUT 800;"DISP:ANN:TITL1:DATA '";Dut$;"'"

50 OUTPUT 800;"DISP:ANN:TITL1 ON"

60 END

DISPLAY

More Display

Title and Clock

Title Line 1
