Automating Measurements 7-7
Displaying Measurement Results
Customized X-axis Annotation
To turn the X-axis annotation on or off
To turn the X-axis (frequency) annotation on or off, press
or use
the following SCPI commands:
DISP:ANN:FREQ[1|2] ON
DISP:ANN:FREQ[1|2] OFF
NOTE When using custom X-axis annotation, the SCPI command
CALC:MARK:X and query CALC:MARK:X? will return the analyzer's
stimulus value, not your custom annotation values. If this is a problem,
you can use the SCPI command CALC:MARK:POIN to specify the X-axis
point number at which you wish to position the marker.
For example:
OUTPUT @HP8711;"CALC:MARK1:POIN 134"
will put the marker at point number 134.
Custom X-axis annotation has no effect on Y-axis marker values
(CALC:MARK:Y?).
