HP 8712ET User Guide Supplement

Automating Measurements 7-3
Displaying Measurement Results
Graticule On/Off
Graticule On/Off
The graticule is the set of grid lines that designate increments of value
on the X-axis and Y-axis of the measurement.
If you are comparing the trace against limit lines or marker values,
turning off the graticule makes it easier to view the measurement trace,
limit lines, and markers. To turn the graticule off, press
or use the following SCPI
command:
DISPlay:WINDow[1|2]:TRACe:GRATicule:GRID OFF
where the window number is 1 if in full-screen display, and 1 or 2 for the
upper and lower split-screen displays.
DISPLAY
More Display
Graticule ON off
