2.2 Check Upgrade Components
Before you begin systematic shutdown of your system, double-check your
upgrade kit contents to be certain you have all necessary components.
Assemble your tools. Clear a space around the side and rear of the cabinet
into which you are going to install the I/O drawer.
Table 2–1 Items Needed for I/O Upgrade
Amt Part Number Description
1 3X-BA70A-AA OR
3X-BA70A-BA OR
3X-BA70B-AA OR
3X-BA70B-BA
I/O master drawer OR
I/O expansion drawer OR
High-performance I/O master drawer OR
High-performance I/O expansion drawer
1 CK-BA70A-AA OR
CK-BA70B-AA
Accessory kit (see Table 1–2 for content details)
1 See Table 2–2 I/O cable(s) (ordered separately)
Prepare the System 2-3
