3.9 Identify I/O Connector on CPU Drawer
Use the tables in Figure 3–10 to identify the cabinet, drawer, and slot number
of the port to which your I/O drawer will connect.
Figure 3–10 CPU Drawer I/O Cable Connections for GS1280
