11. If you need to remove the wireless antennas, peel the antennas o the display rear cover (1), remove
the antenna cables from the routing clips along the bottom and sides of the cover (2), and then remove
the antennas and cables (3).
The antennas and cables are available as spare part number L91533-001.
The display rear cover is available as the following spare part numbers:
L91529-001: Forest teal
L91530-001: Mineral silver
L91531-001: Ceramic white
M41236-001: Pale rose gold
Reverse this procedure to reassemble and replace the display assembly.
Keyboard with top cover
The top cover with keyboard remains after removing all other spare parts from the computer. In this section,
the rst table provides the main spare part number for the top cover/keyboards. The second table provides
the country codes.
Table 5-9 Keyboard with top cover descriptions and part numbers
Description Spare part number
Snow white; no backlight L91515-xx1
Snow white; backlit L91516-xx1
Ash grey; no backlight L91511-xx1
Ash grey; backlit L91512-xx1
Natural silver; no backlight L91513-xx1
Natural silver; backlit L91514-xx1
Jet black, no backlight, no B&O logo on top cover M74072-xx1
Component replacement procedures 47
