Battery
Description Spare part number
Battery (3-cell, 60-WHr) L29959-005
Before removing the battery, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 18).
2. Remove the bottom cover (see Computer feet and bottom cover on page 18).
Remove the battery:
1. Disconnect the battery cable (1) from the system board.
2. Remove the ve Phillips M2.0×3.0 screws (2) that secure the battery to the computer.
3. Remove the battery (3).
Reverse this procedure to install the battery.
20 Chapter 5 Removal and replacement procedures
