Lock bracket
Description Spare part number
Lock bracket L36911-001
Before removing the lock bracket, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 18).
2. Remove the bottom cover (see Computer feet and bottom cover on page 18).
3. Remove the battery (see Battery on page 20).
4. Remove the I/O board (see USB bracket, I/O board on page 32).
Remove the lock bracket:
1. Remove the Phillips M2.5×3.0 screw (1) that secures the lock bracket to the computer.
2. Remove the lock bracket (2).
Reverse this procedure to install the lock bracket.
Component replacement procedures 33
