12. Replace the center access panel. Insert the tabs on the bottom of the access panel into the slots on
the chassis then press the top of the panel straight down so that it snaps in place.
Figure 2-31 Replacing the Center Access Panel
13. To attach the computer to a monitor arm, insert four 10mm screws through the holes on the
monitor arm plate and into the VESA mounting holes on the computer.
NOTE: HP offers an optional monitor arm specifically designed for this product.
To attach the computer to other mounting fixtures, follow the instructions included with the
mounting fixture to ensure that the computer is safely attached.
Figure 2-32 Mounting the Computer
14. Reconnect the cables and turn on the computer.
36 Chapter 2 Hardware Upgrades ENWW
