Page #111 background imageLoading...
Page #111 background image
NOTE: You can use either a pointing device (TouchPad, pointing stick, or USB mouse) or the
keyboard to navigate and make selections in Computer Setup.
To select a menu or a menu item, use the keyboard arrow keys and then press enter, or use
a pointing device to click the item.
To scroll up and down, click the plus sign (+) or the minus sign (-) in the upper-right corner of
the screen.
To close open dialog boxes and return to the main Computer Setup screen, press esc, and
then follow the on-screen instructions.
2. Press f10 to enter BIOS Setup.
3. Select the File, Security, Diagnostics, or System Configuration menu.
To exit Computer Setup menus, choose one of the following methods:
To exit Computer Setup menus without saving your changes, click Exit in the lower-left corner of
the screen, and then follow the on-screen instructions.
– or –
Use the arrow keys to select File > Ignore changes and exit, and then press enter.
– or –
To save your changes and exit Computer Setup menus, click Save in the lower-left corner of the
screen, and then follow the on-screen instructions.
– or –
Use the arrow keys to select File > Save changes and exit, and then press enter.
Your changes go into effect when the computer restarts.
Restoring factory settings in Computer Setup
NOTE: Restoring defaults will not change the hard drive mode.
To return all settings in Computer Setup to the values that were set at the factory, follow these steps:
1. Turn on or restart the computer, and then press esc while the “Press the ESC key for Startup Menu”
message is displayed at the bottom of the screen.
2. Press f10 to enter BIOS Setup.
3. Use a pointing device or the arrow keys to select File > Restore defaults.
4. Follow the on-screen instructions.
5. To save your changes and exit, click Save in the lower-left corner of the screen, and then follow
the on-screen instructions.
– or –
Use the arrow keys to select File > Save changes and exit, and then press enter.
Your changes go into effect when the computer restarts.
Using Computer Setup 103

Table of Contents

Other manuals for HP Compaq 6730b

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Compaq 6730b and is the answer not in the manual?

HP Compaq 6730b Specifications

General IconGeneral
HDD speed5400 RPM
Optical drive typeDVD Super Multi DL
Card reader integratedNo
Total storage capacity160 GB
Memory slots2x SO-DIMM
Internal memory2 GB
Internal memory typeDDR2-SDRAM
Maximum internal memory8 GB
Bus typeFSB
SteppingM0
Tjunction105 °C
Processor cache3 MB
Processor cores2
System bus rate- GT/s
Processor familyIntel® Core™2 Duo
Processor seriesIntel Core 2 Duo P8000 Series
Processor socketSocket 478
Processor codenamePenryn
Processing Die size107 mm²
Processor frequency2.26 GHz
Processor cache typeL2
Processor technologyIntel Centrino 2
Processor lithography45 nm
Processor manufacturerIntel
Processor front side bus1066 MHz
Processor operating modes64-bit
Thermal Design Power (TDP)25 W
CPU multiplier (bus/core ratio)8.5
Number of Processing Die Transistors410 M
Motherboard chipsetIntel GE45 Express
Display surfaceMatt
Display diagonal15.4 \
TypePC
ErgonomicsTouch-sensitive controls
LightScribeYes
Modem speed56 Kbit/s
Expansion slotsSlots available for additional devices: 1 ExpressCard/54 slot, Media Card Reader
Power requirements90W HP Smart AC Adapter, 90W Smart Combo Adapter, HP Fast Charge 6-cell (55 WHr) Lithium-Ion battery, optional HP (52 WHr) Extended Life Battery, optional HP (95 WHr) Ultra-Capacity Battery
Wireless technology802.11a/b/g/draft-n
Compatible operating systemsGenuine Windows Vista Business 64-bit, Genuine Windows Vista Enterprise, SuSe Linux Enterprise Desktop 10
Audio systemHD
Audio includedHigh Definition Audio, stereo speakers, stereo headphone/line out, stereo microphone in, integrated microphone (integrated dual-microphone array with optional integrated VGA webcam; VoIP ready)
Networking typeGigabit Ethernet
Networking featuresBroadcom NetLink Gigabit Ethernet PCI Controller (10/100/1000 NIC)
Operating system installedWindows Vista Business
Number of battery cells6
I/O ports4 USB 2.0 ports, VGA, S-video TV out, stereo microphone in, stereo headphone/line out, Firewire (1394a), power connector, RJ-11, RJ-45, serial port
TV-out typeS-Video
Charging port typeDC-in jack
USB 2.0 ports quantity4
Parallel ports quantity0
Cable lock slot typeKensington
Keyboard typeFull-sized
Pointing deviceTouchpad + Scroll zone
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 35 °C
Storage relative humidity (H-H)5 - 95 %
Operating relative humidity (H-H)10 - 90 %
Video card featuresMobile Intel Graphics Media Accelerator 4500MHD
Discrete graphics card modelIntel® GMA 4500MHD
Processor codeSL3BU
Processor ARK ID35569
Processor package size35 x 35 mm
Country of originChina
Weight and Dimensions IconWeight and Dimensions
Depth266 mm
Width356 mm
Weight2700 g
Height (front)34 mm
