Display assembly
NOTE: All display assembly spare part kits include 2 WLAN antenna transceivers and cables.
Description Spare part number
Display assemblies for use only with HP Compaq 6735b computer models:
15.4-inch SXGA+ display assembly with 2 microphones and webcam for use only with
computer models equipped with both WLAN and WWAN modules
492177-001
15.4-inch SXGA+ display assembly with 1 microphone for use only with computer models
equipped with both WLAN and WWAN modules
492178-001
15.4-inch SXGA+ display assembly with 2 microphones and webcam for use only with
computer models equipped with a WLAN module but not a WWAN module
492179-001
15.4-inch SXGA+ display assembly with 1 microphone for use only with computer models
equipped with a WLAN module but not a WWAN module
492180-001
15.4-inch WXGA BrightView display assembly with 2 microphones and webcam for use only
with computer models equipped with both WLAN and WWAN modules
492181-001
15.4-inch WXGA BrightView display assembly with 1 microphone for use only with computer
models equipped with both WLAN and WWAN modules
492182-001
15.4-inch WXGA Brightview display assembly with 2 microphones and webcam for use only
with computer models equipped with a WLAN module but not a WWAN module
492183-001
15.4-inch WXGA Brightview display assembly with 1 microphone for use only with computer
models equipped with a WLAN module but not a WWAN module
492184-001
15.4-inch WXGA display assembly with 2 microphones and webcam for use only with
computer models equipped with both WLAN and WWAN modules
492173-001
15.4-inch WXGA display assembly with 1 microphone for use only with computer models
equipped with both WLAN and WWAN modules
492174-001
15.4-inch WXGA display assembly with 2 microphones and webcam for use only with
computer models equipped with a WLAN module but not a WWAN module
492175-001
15.4-inch WXGA display assembly with 1 microphone for use only with computer models
equipped with a WLAN module but not a WWAN module
492176-001
Display assemblies for use only with HP Compaq 6730b computer models:
15.4-inch SXGA+ display assembly with 2 microphones and webcam for use only with
computer models equipped with both WLAN and WWAN modules
487126-001
15.4-inch SXGA+ display assembly with 1 microphone for use only with computer models
equipped with both WLAN and WWAN modules
487127-001
15.4-inch SXGA+ display assembly with 2 microphones and webcam for use only with
computer models equipped with a WLAN module but not a WWAN module
487128-001
15.4-inch SXGA+ display assembly with 1 microphone for use only with computer models
equipped with a WLAN module but not a WWAN module
487129-001
15.4-inch WXGA BrightView display assembly with 2 microphones and webcam for use only
with computer models equipped with both WLAN and WWAN modules
487130-001
15.4-inch WXGA BrightView display assembly with 1 microphone for use only with computer
models equipped with both WLAN and WWAN modules
487131-001
15.4-inch WXGA BrightView display assembly with 2 microphones and webcam for use only
with computer models equipped with a WLAN module but not a WWAN module
487132-001
74 Chapter 4 Removal and replacement procedures
