HP Compaq 6730b Maintenance And Service Guide

Description Spare part number
●
Torx T8M2.5×6.0 screw
●
Torx T8M2.5×4.0 screw
Sequential part number listing
Spare part
number
Description
246959-001 Power cord for use in the United States
246959-011 Power cord for use in Australia and New Zealand
246959-021 Power cord for use in Europe, the Middle East, and Africa
246959-031 Power cord for use in the United Kingdom
246959-061 Power cord for use in Italy
246959-081 Power cord for use in Denmark
246959-201 Power cord for use in Brazil
246959-291 Power cord for use in Japan
246959-AD1 Power cord for use in South Korea
246959-AG1 Power cord for use in Switzerland
246959-BB1 Power cord for use in Israel
449137-001 RTC battery
463955-001 90-W HP Smart AC adapter for use in all countries and regions except India
463956-001 90-W HP Smart AC adapter for use only in India
480985-001 Intel Wi-Fi Link 5100 802.11a/b/g/n WLAN module for use only with HP Compaq 6730b computer models in
all countries and regions
482957-001 Intel Wi-Fi Link 5100 802.11a/b/g WLAN module for use only with HP Compaq 6730b computer models in all
countries and regions
483193-001 1024-MB memory module (PC2-6400, 667-MHz, DDR2)
483194-001 2048-MB memory module (PC2-6400, 667-MHz, DDR2)
483377-001 HSDPA EVDO WWAN module
486247-001 System board for use only with HP Compaq 6730b computer models equipped with both WLAN and WWAN
modules (includes replacement thermal material)
486248-001 System board for use only with HP Compaq 6730b computer models equipped with a WLAN module but not
a WWAN module (includes replacement thermal material)
486249-001 USB/digital media board (includes cable)
486250-001 Audio board (includes cable)
486252-001 SIM connector board
486254-001 Intel Core 2 Duo T8400 2.26-GHz processor for use only with HP Compaq 6730b computer models (3-MB
L2 cache, 800-MHz FSB, includes replacement thermal material)
Sequential part number listing 31

HP Compaq 6730b Specifications

General

HDD speed	5400 RPM
Optical drive type	DVD Super Multi DL
Card reader integrated	No
Total storage capacity	160 GB
Memory slots	2x SO-DIMM
Internal memory	2 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Bus type	FSB
Stepping	M0
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo P8000 Series
Processor socket	Socket 478
Processor codename	Penryn
Processing Die size	107 mm²
Processor frequency	2.26 GHz
Processor cache type	L2
Processor technology	Intel Centrino 2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	1066 MHz
Processor operating modes	64-bit
Thermal Design Power (TDP)	25 W
CPU multiplier (bus/core ratio)	8.5
Number of Processing Die Transistors	410 M
Motherboard chipset	Intel GE45 Express
Display surface	Matt
Display diagonal	15.4 \
Type	PC
Ergonomics	Touch-sensitive controls
LightScribe	Yes
Modem speed	56 Kbit/s
Expansion slots	Slots available for additional devices: 1 ExpressCard/54 slot, Media Card Reader
Power requirements	90W HP Smart AC Adapter, 90W Smart Combo Adapter, HP Fast Charge 6-cell (55 WHr) Lithium-Ion battery, optional HP (52 WHr) Extended Life Battery, optional HP (95 WHr) Ultra-Capacity Battery
Wireless technology	802.11a/b/g/draft-n
Compatible operating systems	Genuine Windows Vista Business 64-bit, Genuine Windows Vista Enterprise, SuSe Linux Enterprise Desktop 10
Audio system	HD
Audio included	High Definition Audio, stereo speakers, stereo headphone/line out, stereo microphone in, integrated microphone (integrated dual-microphone array with optional integrated VGA webcam; VoIP ready)
Networking type	Gigabit Ethernet
Networking features	Broadcom NetLink Gigabit Ethernet PCI Controller (10/100/1000 NIC)
Operating system installed	Windows Vista Business
Number of battery cells	6
I/O ports	4 USB 2.0 ports, VGA, S-video TV out, stereo microphone in, stereo headphone/line out, Firewire (1394a), power connector, RJ-11, RJ-45, serial port
TV-out type	S-Video
Charging port type	DC-in jack
USB 2.0 ports quantity	4
Parallel ports quantity	0
Cable lock slot type	Kensington
Keyboard type	Full-sized
Pointing device	Touchpad + Scroll zone
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Video card features	Mobile Intel Graphics Media Accelerator 4500MHD
Discrete graphics card model	Intel® GMA 4500MHD
Processor code	SL3BU
Processor ARK ID	35569
Processor package size	35 x 35 mm
Country of origin	China

Weight and Dimensions

Depth	266 mm
Width	356 mm
Weight	2700 g
Height (front)	34 mm
