HP Compaq 6730b Maintenance And Service Guide

Spare part
number
Description
486255-001 Intel Core 2 Duo T8600 2.40-GHz processor for use only with HP Compaq 6730b computer models (3-MB
L2 cache, 800-MHz FSB, includes replacement thermal material)
486256-001 Intel Core 2 Duo T9400 2.53-GHz processor for use only with HP Compaq 6730b computer models (6-MB
L2 cache, 800-MHz FSB, includes replacement thermal material)
486257-001 Intel Core 2 Duo T9600 2.80-GHz processor for use only with HP Compaq 6730b computer models (6-MB
L2 cache, 800-MHz FSB, includes replacement thermal material)
486259-001 120-GB, 7200-rpm hard drive (includes hard drive bracket)
486260-001 160-GB, 5400-rpm hard drive (includes hard drive bracket)
486261-001 250-GB, 5400-rpm hard drive (includes hard drive bracket)
486262-001 DVD±RW and CD-RW SuperMulti Double-Layer Combo Drive
486263-001 DVD/CD-RW Combo Drive
486264-001 DVD-ROM Drive
486288-001 Fan
486289-001 Heat sink for use only with HP Compaq 6730b computer models (includes heat sink clip and replacement
thermal material)
486290-001 Display Logo Kit
486291-001 System board bracket
486292-001 Plastics Kit (see Plastics Kit on page 27 for more Plastics Kit spare part information):
486295-001 6-cell, 47-Wh battery
486296-001 6-cell, 55-Wh battery
486773-001 Display inverter for use only with HP Compaq 6730b computer models
486775-001 Display Rubber Kit
486782-001 120-GB, 5400-rpm hard drive (includes hard drive bracket)
487118-001 Power button board (includes cable)
487119-001 ExpressCard board (includes RTC battery)
487121-001 Optical drive connector board
487122-001 15.4-inch WXGA display assembly with 2 microphones and webcam for use only with HP Compaq 6730b
computer models equipped with both WLAN and WWAN modules (include 2 WLAN antenna transceivers and
cables)
487123-001 15.4-inch WXGA display assembly with 1 microphone for use only with HP Compaq 6730b computer models
equipped with both WLAN and WWAN modules (include 2 WLAN antenna transceivers and cables)
487124-001 15.4-inch WXGA display assembly with 2 microphones and webcam for use only with HP Compaq 6730b
computer models equipped with a WLAN module but not a WWAN module (include 2 WLAN antenna
transceivers and cables)
487125-001 15.4-inch WXGA display assembly with 1 microphone for use only with HP Compaq 6730b computer models
equipped with a WLAN module but not a WWAN module (include 2 WLAN antenna transceivers and cables)
487126-001 15.4-inch SXGA+ display assembly with 2 microphones and webcam for use only with HP Compaq 6730b
computer models equipped with both WLAN and WWAN modules (include 2 WLAN antenna transceivers and
cables)
32 Chapter 3 Illustrated parts catalog

HP Compaq 6730b Specifications

General

HDD speed	5400 RPM
Optical drive type	DVD Super Multi DL
Card reader integrated	No
Total storage capacity	160 GB
Memory slots	2x SO-DIMM
Internal memory	2 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Bus type	FSB
Stepping	M0
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo P8000 Series
Processor socket	Socket 478
Processor codename	Penryn
Processing Die size	107 mm²
Processor frequency	2.26 GHz
Processor cache type	L2
Processor technology	Intel Centrino 2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	1066 MHz
Processor operating modes	64-bit
Thermal Design Power (TDP)	25 W
CPU multiplier (bus/core ratio)	8.5
Number of Processing Die Transistors	410 M
Motherboard chipset	Intel GE45 Express
Display surface	Matt
Display diagonal	15.4 \
Type	PC
Ergonomics	Touch-sensitive controls
LightScribe	Yes
Modem speed	56 Kbit/s
Expansion slots	Slots available for additional devices: 1 ExpressCard/54 slot, Media Card Reader
Power requirements	90W HP Smart AC Adapter, 90W Smart Combo Adapter, HP Fast Charge 6-cell (55 WHr) Lithium-Ion battery, optional HP (52 WHr) Extended Life Battery, optional HP (95 WHr) Ultra-Capacity Battery
Wireless technology	802.11a/b/g/draft-n
Compatible operating systems	Genuine Windows Vista Business 64-bit, Genuine Windows Vista Enterprise, SuSe Linux Enterprise Desktop 10
Audio system	HD
Audio included	High Definition Audio, stereo speakers, stereo headphone/line out, stereo microphone in, integrated microphone (integrated dual-microphone array with optional integrated VGA webcam; VoIP ready)
Networking type	Gigabit Ethernet
Networking features	Broadcom NetLink Gigabit Ethernet PCI Controller (10/100/1000 NIC)
Operating system installed	Windows Vista Business
Number of battery cells	6
I/O ports	4 USB 2.0 ports, VGA, S-video TV out, stereo microphone in, stereo headphone/line out, Firewire (1394a), power connector, RJ-11, RJ-45, serial port
TV-out type	S-Video
Charging port type	DC-in jack
USB 2.0 ports quantity	4
Parallel ports quantity	0
Cable lock slot type	Kensington
Keyboard type	Full-sized
Pointing device	Touchpad + Scroll zone
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Video card features	Mobile Intel Graphics Media Accelerator 4500MHD
Discrete graphics card model	Intel® GMA 4500MHD
Processor code	SL3BU
Processor ARK ID	35569
Processor package size	35 x 35 mm
Country of origin	China

Weight and Dimensions

Depth	266 mm
Width	356 mm
Weight	2700 g
Height (front)	34 mm
