HP Compaq 6730b Maintenance And Service Guide

Select To do this
●
Enable/disable CD-ROM boot (enabled by default).
●
Enable/disable SD Card boot (enabled by default).
●
Enable/disable diskette boot (enabled by default).
●
Enable/disable boot from Extensible Firmware Interface (EFI) File (select models only;
enabled by default).
●
Enable/disable internal network adapter boot and set the Preboot eXecution
Environment (PXE) (enabled by default).
●
Set the Express Boot Popup delay in seconds.
●
Set the boot order.
Device Configurations
●
Enable/Disable Unified Extensible Firmware Interface (UEFI) mode (disabled by
default).
●
Enable/disable USB legacy support (enabled by default). When enabled, USB legacy
support allows the following:
◦
Use of a USB keyboard in Computer Setup even when a Windows® operating
system is not running.
◦
Startup from bootable USB devices, including a hard drive, diskette drive, or
optical drive connected by a USB port to the computer.
●
Select a parallel port mode: ECP (Enhanced Capabilities Port), standard, bidirectional,
or EPP (Enhanced Parallel Port).
●
Enable/disable BIOS DMA data transfers (select models only; enabled by default).
●
Enable/disable fan always on while connected to an AC outlet (disabled by default).
●
Enable/disable LAN Power Save. When enabled, saves power by turning off the LAN
when not in use (enabled by default).
●
Enable/disable Data Execution Prevention. When enabled, the processor can disable
some virus code execution, which helps to improve computer security.
●
SATA (Serial Advanced Technology Attachment) device mode. The following options
are available:
◦
AHCI (Advanced Host Controller Interface)
◦
IDE (Integrated Drive Electronics)
NOTE: Availability of the options above varies by computer model.
●
Enable/disable secondary battery fast charge (enabled by default).
●
Enable/disable HP QuickLook 2 (enabled by default).
●
Enable/disable Virtualization Technology (select models only; enabled by default).
●
Enable/disable TXT (Intel® Trusted Execution Technology) (select models only;
enabled by default).
●
Enable/disable Dual Core CPU (select models only; enabled by default).
Built-In Device Options
●
Enable/disable the wireless button state (enabled by default).
●
Enable/disable embedded WWAN device radio (select models only; enabled by
default).
106 Chapter 5 Computer Setup

HP Compaq 6730b Specifications

General

HDD speed	5400 RPM
Optical drive type	DVD Super Multi DL
Card reader integrated	No
Total storage capacity	160 GB
Memory slots	2x SO-DIMM
Internal memory	2 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Bus type	FSB
Stepping	M0
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo P8000 Series
Processor socket	Socket 478
Processor codename	Penryn
Processing Die size	107 mm²
Processor frequency	2.26 GHz
Processor cache type	L2
Processor technology	Intel Centrino 2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	1066 MHz
Processor operating modes	64-bit
Thermal Design Power (TDP)	25 W
CPU multiplier (bus/core ratio)	8.5
Number of Processing Die Transistors	410 M
Motherboard chipset	Intel GE45 Express
Display surface	Matt
Display diagonal	15.4 \
Type	PC
Ergonomics	Touch-sensitive controls
LightScribe	Yes
Modem speed	56 Kbit/s
Expansion slots	Slots available for additional devices: 1 ExpressCard/54 slot, Media Card Reader
Power requirements	90W HP Smart AC Adapter, 90W Smart Combo Adapter, HP Fast Charge 6-cell (55 WHr) Lithium-Ion battery, optional HP (52 WHr) Extended Life Battery, optional HP (95 WHr) Ultra-Capacity Battery
Wireless technology	802.11a/b/g/draft-n
Compatible operating systems	Genuine Windows Vista Business 64-bit, Genuine Windows Vista Enterprise, SuSe Linux Enterprise Desktop 10
Audio system	HD
Audio included	High Definition Audio, stereo speakers, stereo headphone/line out, stereo microphone in, integrated microphone (integrated dual-microphone array with optional integrated VGA webcam; VoIP ready)
Networking type	Gigabit Ethernet
Networking features	Broadcom NetLink Gigabit Ethernet PCI Controller (10/100/1000 NIC)
Operating system installed	Windows Vista Business
Number of battery cells	6
I/O ports	4 USB 2.0 ports, VGA, S-video TV out, stereo microphone in, stereo headphone/line out, Firewire (1394a), power connector, RJ-11, RJ-45, serial port
TV-out type	S-Video
Charging port type	DC-in jack
USB 2.0 ports quantity	4
Parallel ports quantity	0
Cable lock slot type	Kensington
Keyboard type	Full-sized
Pointing device	Touchpad + Scroll zone
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Video card features	Mobile Intel Graphics Media Accelerator 4500MHD
Discrete graphics card model	Intel® GMA 4500MHD
Processor code	SL3BU
Processor ARK ID	35569
Processor package size	35 x 35 mm
Country of origin	China

Weight and Dimensions

Depth	266 mm
Width	356 mm
Weight	2700 g
Height (front)	34 mm
