Item Description Spare part number

(24) Base enclosures

For use only with computer models equipped with both WLAN and WWAN modules 487142-001

For use only with computer models equipped with a WLAN module but not a WWAN

module

487141-001

Rubber Kit (not illustrated, includes 8 rubber feet and 2 rubber screw covers) 487145-001

(25) Batteries

6-cell, 55-Wh 486296-001

6-cell, 47-Wh 486295-001

(26) Optical drives (include bezel and bracket)

DVD±RW and CD-RW SuperMulti Double-Layer Combo Drive 486262-001

DVD/CD-RW Combo Drive 486263-001

DVD-ROM Drive 486264-001

(27) RTC battery 449137-001

(28) Hard drives: (include hard drive bracket)

250-GB, 5400-rpm 486261-001

160-GB, 5400-rpm 486260-001

120-GB, 7200-rpm 486259-001

120-GB, 5400-rpm 486782-001

(29) WLAN modules

Broadcom WLAN modules for use only with HP Compaq 6735b computer models:

●

Broadcom 4322 802.11a/b/g/n WLAN module for use in Antigua and Barbuda,

Barbados, Belize, Canada, the Cayman Islands, Guam, Puerto Rico,

Trinidad and Tobago, the U.S. Virgin Islands, and the United States

487330-001

●

Broadcom 4322 802.11a/b/g/n WLAN module for use in Afghanistan, Albania,

Algeria, Andorra, Angola, Antigua and Barbuda, Argentina, Armenia, Aruba,

Australia, Austria, Azerbaijan, the Bahamas, Bahrain, Bangladesh, Barbados,

Belarus, Belgium, Belize, Benin, Bermuda, Bhutan, Bolivia,

Bosnia and Herzegovina, Botswana, Brazil, the British Virgin Islands, Brunei,

Bulgaria, Burkina Faso, Burundi, Cameroon, Cape Verde,

the Central African Republic, Chad, Chile, the People's Republic of China,

Colombia, Comoros, the Congo, Costa Rica, Croatia, Cyprus,

the Czech Republic, Denmark, Djibouti, Dominica, the Dominican Republic,

East Timor, Ecuador, Egypt, El Salvador, Equitorial Guinea, Eritrea, Estonia,

Ethiopia, Fiji, Finland, France, French Guiana, Gabon, Gambia, Georgia,

Germany, Ghana, Gibraltar, Greece, Grenada, Guadeloupe, Guatemala, Guinea,

Guinea-Bissau, Guyana, Haiti, Honduras, Hong Kong, Hungary, Iceland, India,

Ireland, Israel, Italy, the Ivory Coast, Jamaica, Jordan, Kazakhstan, Kenya,

Kiribati, Kyrgyzstan, Laos, Latvia, Lebanon, Lesotho, Liberia, Liechtenstein,

Lithuania, Luxembourg, Macedonia, Madagascar, Malawi, Malaysia,

the Maldives, Mali, Malta, the Marshall Islands, Martinique, Mauritania, Mauritius,

Mexico, Micronesia, Monaco, Mongolia, Montenegro, Morocco, Mozambique,

Namibia, Nauru, Nepal, the Nether Antilles, the Netherlands, New Zealand,

Nicaragua, Niger, Nigeria, Norway, Oman, Pakistan, Palau, Panama,

Papua New Guinea, Paraguay, Peru, the Philippines, Poland, Portugal,

the Republic of Moldova, Romania, Russia, Rwanda, Samoa, San Marino,

Sao Tome and Principe, Saudi Arabia, Senegal, Serbia, the Seychelles,

487330-002

Computer major components 25
