2–6 www.hp.com Hardware Reference Guide
Hardware Upgrades
Removing the Front Bezel
1. Turn off the computer properly through the operating system and
turn off any external devices. Disconnect the power cord from the
power outlet and disconnect any external devices.
2. Remove the computer cover. See the “Removing the Computer
Cover” procedure.
3. Pull up on the two release tabs on the left side of the bezel and
push the release tab on the right side of the bezel in toward the
center of the chassis 1, then rotate the front bezel away from the
chassis to release it 2.
Removing the Front Bezel
When replacing the front bezel, ensure that the bottom hinge points
are properly placed in the chassis before rotating the front bezel back
into its original position.

Other manuals for HP Compaq d330 DT

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Compaq d330 DT and is the answer not in the manual?

HP Compaq d330 DT Specifications

General IconGeneral
ChipsetIntel 845GV
RAMUp to 2 GB
Memory TypeDDR SDRAM
Memory Slots2
GraphicsIntegrated Intel Extreme Graphics
AudioIntegrated AC'97 audio
Network ControllerIntegrated 10/100 Ethernet
Power Supply250W
Form FactorDesktop
ProcessorIntel Pentium 4
Hard Drive40 GB
Optical DriveCD-ROM
Front Ports2 USB 2.0
Rear Ports4 USB 2.0, serial, parallel, VGA
Operating SystemWindows XP Professional
Processor SpeedUp to 3.06 GHz (Pentium 4), Up to 2.0 GHz (Celeron)
