2–14 www.hp.com Hardware Reference Guide
Hardware Upgrades
6. If you are removing an expansion card from a standard expansion
socket, hold the card at each end and carefully rock it back and
forth until the connectors pull free from the socket. Lift the
expansion card straight up 1 then pull it in toward the center of
the chassis 2 to release it from the chassis frame. Be sure not to
scrape the card against other components.
✎
Before removing an installed expansion card, disconnect any cables
that may be attached to the expansion card.
Removing an Expansion Card from a Standard Expansion Socket
