2–26 www.hp.com Hardware Reference Guide
Hardware Upgrades
5. Install four guide screws, two on each side of the drive.
Installing the Guide Screws
✎
Extra guide screws are provided on the chassis basepan, under the
front bezel. Hard drives use 6-32 standard screws. All other drives use
M3 metric screws. The HP-supplied metric screws are black. The
HP-supplied standard screws are silver.
6. Lift up on the hard drive bracket 1, then rotate it down 2 to gain
access to the drive bay.
Opening the Hard Drive Bracket
