6–12 437804-001 Service Reference Guide, dc5700
Removal and Replacement Procedures— Microtower (MT) Chassis
4. Before installing an expansion card, remove the expansion slot cover or the existing
expansion card.
✎
Before removing an installed expansion card, disconnect any cables that may be attached to the
expansion card.
a. If you are installing an expansion card in a vacant socket, remove the appropriate
expansion slot cover on the back of the chassis. Pull the slot cover straight up from the
socket then away from the inside of the chassis.
b. If removing a standard PCI expansion card, hold the card at each end, and carefully rock
it back and forth until the connectors pull free from the socket. Pull the expansion card
straight up from the socket 1 then away from the inside of the chassis 2 to release it
from the chassis frame. Be sure not to scrape the card against the other components.

HP Compaq dc5700 MT Specifications

General

Chipset	Intel Q965 Express
Audio	Integrated High Definition audio
Network	Integrated Broadcom NetXtreme Gigabit Ethernet
Power Supply	300W
Form Factor	Microtower
Processor	Intel Pentium D, Intel Celeron D
Memory	Up to 4 GB DDR2
Graphics	Intel Graphics Media Accelerator 3000
Optical Drive	DVD-ROM
Expansion Slots	1 PCI Express x16
Ports	USB 2.0, VGA, serial, parallel
Operating System	Windows XP Professional, Windows Vista
Storage	SATA Hard Drive
