HP Compaq dc5750 SFF User Manual

Using the Small Form Factor Computer in a Tower
Orientation
The Small Form Factor computer can be used in a tower orientation by purchasing an optional tower
stand. The HP logo plate on the front bezel is adjustable for either desktop or tower orientation.
1. Remove/disengage any security devices that prohibit opening the computer.
2. Remove all removable media, such as diskettes or compact discs, from the computer.
3. Turn off the computer properly through the operating system, then turn off any external devices.
4. Disconnect the power cord from the power outlet and disconnect any external devices.
CAUTION Regardless of the power-on state, voltage is always present on the system
board as long as the system is plugged into an active AC outlet. You must disconnect the
power cord to avoid damage to the internal components of the computer.
5. Remove the access panel.
6. Remove the front bezel.
7. Squeeze together the two sides of the peg on the back side of the logo plate (1) and push the peg
inwards towards the front side of the bezel (2).
8. Rotate the plate 90 degrees (3) then pull back on the peg to lock the logo plate in place.
9. Replace the front bezel.
10. Replace the access panel.
8 Chapter 2 Hardware Upgrades ENWW

HP Compaq dc5750 SFF Specifications

General

Chipset	ATI Radeon Xpress 1150
Memory	Up to 4 GB DDR2 SDRAM
Audio	Integrated High Definition audio
Network	Integrated Broadcom NetXtreme Gigabit Ethernet
Power Supply	240W
Form Factor	Small Form Factor (SFF)
Processor	AMD Athlon 64 X2, AMD Sempron
Storage	SATA Hard Drive
Optical Drive	DVD-ROM, DVD+/-RW
Expansion Slots	1 PCI, 1 PCI Express x16, 1 PCI Express x1
Ports	1 serial, 1 parallel, 1 VGA, audio in/out
Operating System	Windows XP Professional, Windows Vista
