Drive Positions
Figure 2-18 Drive Positions
1 5.25-inch external drive bay for optional drives (optical drive shown)
2 3.5-inch external drive bay for optional drives (diskette drive shown)
1
3 3.5-inch internal hard drive bay
1
You can install a diskette drive, a media card reader, or a second SATA hard drive in the external
3.5-inch bay.
To verify the type, size, and capacity of the storage devices installed in the computer, run Computer
Setup. Refer to the Computer Setup (F10) Utility Guide on the Documentation and Diagnostics CD for
more information.
26 Chapter 2 Hardware Upgrades ENWW
