HP Compaq dc5750 SFF - Removing the Optical Drive

9. Press down on the lever to the left of the drive (1), slide the drive back until it stops, and lift it straight
up and out the drive bay (2).
NOTE Hold the front and back of the drive when lifting it out of the drive bay.
Figure 2-8 Removing the Optical Drive
10. Rotate the optical drive retainer to its upright position to access the memory module sockets.
Figure 2-9 Rotating Optical Drive Retainer Up
18 Chapter 2 Hardware Upgrades ENWW
