HP Compaq dc7100 SFF User Manual

Technical Reference Guide 361834-001 7-3
Power and Signal Distribution
NOTES:
Total continuous power should not exceed 300 watts. Total continuous power (excluding 5 V aux output) should not exceed 290
watts
[1] Minimum loading requirements must be met at all times to ensure normal operation and specification compliance.
[2] Surge duration no longer than 10 seconds with 12-volt tolerance +/- 10%.
Table 7-4 lists the specifications for the 340-watt power supply used in the CMT form factor and
in some MT form factors.
NOTES:
Total continuous output power should no exceed 340 watts. Maximum surge power should not exceed 360 watts. Total
continuous power (excluding 5 V aux output) should not exceed 325watts.
Maximum combined power of +5 and +3.3 VDC is 160 watts.
[1] Minimum loading requirements must be met at all times to ensure normal operation and specification compliance.
[2] Surge duration no longer than 10 seconds with 12-volt tolerance +/- 10%.
Table 7-3.
300-Watt (MT) Power Supply Assembly Specifications
Range/
Tolerance
Min.
Current
Loading [1]
Max.
Current
Surge
Current [2]
Max.
Ripple
Input Line Voltage:
115 VAC Setting
230 VAC Setting
90 - 132 VAC
180 - 264 VAC
-- -- -- --
Line Frequency 47–63 Hz -- -- -- --
Constant Input (AC) Current -- -- 8.0 / 4.0A -- --
+3.3 VDC Output +
5% 0.1 A 18.0 A 19.0 A 50 mV
+5 VDC Output + 5% 0.3 A 25.0 A 25.0 A 50 mV
+5 AUX Output +
5% 0.0 A 2.0 A 2.0 A 50 mV
+12 VDC Output +
5 % 0.1 A 6.5 A 6.5 A 120 mV
+12 VDC Output (Vcpu) +
5 % 0.1 A 12.5 A 12.5 A 120 mv
--12 VDC Output +
10 % 0.0 A 0.8 A 0.8 A 200 mV
Table 7-4.
340-Watt (MT/CMT) Power Supply Assembly Specifications
Range or
Tolerance
Min.
Current
Loading [1]
Max.
Current
Surge
Current [2]
Max.
Ripple
Input Line Voltage:
115–230 VAC (auto-ranging) 90–132 VAC -- -- -- --
Line Frequency 47–63 Hz -- -- -- --
Input (AC) Current -- -- 6.0 A -- --
+3.3 VDC Output +
4 % 0.10 A 24.0 A 24.0 A 50 mV
+5.08 VDC Output + 3.3 % 0.30 A 19.0 A 19.0 A 50 mV
+5.08 AUX Output +
3.3 % 0.00 A 3.00 A 3.00 A 50 mV
+12 VDC Output +
5 % 0.20 A 12.0 A 14.5 A 120 mV
+12 VDC Output (Vcpu) +
5 % 0.00 A 12.5 A 12.5 A 200 mv
-12 VDC Output +
10 % 0.00 A 0.15 A 0.15 A 200 mV

HP Compaq dc7100 SFF Specifications

General

Processor Speed	Up to 3.8 GHz
Graphics	Integrated Intel Graphics Media Accelerator 900
Audio	Integrated AC'97 audio
Form Factor	Small Form Factor (SFF)
Power Supply	240W
Processor	Intel Pentium 4
Chipset	Intel 915G Express
Memory	Up to 4 GB DDR
Storage	40 GB to 160 GB HDD
Optical Drive	CD-ROM or DVD-ROM
Network	Integrated Intel Gigabit Ethernet
Expansion Slots	1 PCI Express x16
Ports	USB 2.0, serial, parallel, VGA
Operating System	Windows XP Professional
