System Support
APIC Mode
The Advanced Programmable Interrupt Controller (APIC) mode provides enhanced interrupt
processing with the following advantages:
■ Eliminates the processor's interrupt acknowledge cycle by using a separate (APIC) bus
■ Programmable interrupt priority
■ Additional interrupts (total of 24)
The APIC mode accommodates eight PCI interrupt signals (INTA-..INTH-) for use by PCI
devices. The PCI interrupts are evenly distributed to minimize latency and wired as follows:
NOTES:
[1] Connection internal to the ICH. Will be reported by BIOS as using INTA but is NOT shared with
other functions using INTA.
MT, CMT form factors only.
SFF, ST, MT, CMT form factors only.
The PCI interrupts can be configured by PCI Configuration Registers 60h..63h to share the
standard ISA interrupts (IRQn).
✎
The APIC mode is supported by the Windows NT, Windows 2000, and Windows XP operating
systems. Systems running the Windows 95 or 98 operating system will need to run in 8259 mode.
PCI
Slot 1
PCI
Slot 2
PCI
Slot 3
PCI
Slot 4
INTA-
Wired
to
INTA-
INTD- INTB- INTD-
INTB- —
— — —
INTC- INTB-
INTA- INTC- INTA-
INTD- —
— — —
INTE- —
— — —
INTF- INTC-
INTB- INTD- INTB-
INTG- INTD-
INTC- INTA- INTC-
INTH- —
— — —

HP Compaq dc7100 SFF Specifications

General

Processor Speed	Up to 3.8 GHz
Graphics	Integrated Intel Graphics Media Accelerator 900
Audio	Integrated AC'97 audio
Form Factor	Small Form Factor (SFF)
Power Supply	240W
Processor	Intel Pentium 4
Chipset	Intel 915G Express
Memory	Up to 4 GB DDR
Storage	40 GB to 160 GB HDD
Optical Drive	CD-ROM or DVD-ROM
Network	Integrated Intel Gigabit Ethernet
Expansion Slots	1 PCI Express x16
Ports	USB 2.0, serial, parallel, VGA
Operating System	Windows XP Professional
