HP Compaq L2206tm User Manual

Rear components
Figure 3-2 Rear components
Component Description
1 AC power connector Connects the AC power cable to the monitor.
2 DisplayPort Connects the DisplayPort cable to the monitor.
3 VGA connector Connects the VGA cable to the monitor.
4 DVI-D connector Connects the DVI-D cable to the monitor.
5 Audio connector Connects the audio cable to the monitor.
6 USB upstream connector Connects the USB hub cable to the monitor's USB hub connector
and to a host USB port/hub.
7 USB downstream connectors (2) Connect optional USB devices to the monitor.
8 Passive stylus Housed in rear enclosure. When removed, it can be used as a
touch pointing device.
NOTE: The stylus is not required for optical touch applications.
Fingers and other pointing instruments may be used.
6 Chapter 3 Setting up the monitor

HP Compaq L2206tm Specifications

General

3D	No
Pixel pitch	0.248 x 0.248 mm
Aspect ratio	16:9
Display diagonal	21.5 \
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	1000000:1
Contrast ratio (typical)	1000:1
Display number of colors	-
Viewing angle, horizontal	170 °
Display brightness (typical)	220 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
On/off switch	Yes
USB hub version	2.0
HDMI ports quantity	0
USB Type-A downstream ports quantity	2
LED indicators	Power
Tilt angle range	-5 - 30 °
Panel mounting interface	- mm
AC input voltage	100 - 240 V
Power consumption (max)	39 W
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Product color	Black
Country of origin	China
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, Audio (3.5mm), DisplayPort, DVI, USB, VGA

Weight and Dimensions

Depth (with stand)	228 mm
Height (with stand)	445 mm
Weight (with stand)	7000 g
Depth (without stand)	53.6 mm
Width (without stand)	518 mm
Height (without stand)	323.1 mm
Weight (without stand)	- g
