Page #35 background imageLoading...
Page #35 background image
Button lockouts
Holding down the power button or Menu button for ten seconds will lock out the functionality of that
button. You can restore the functionality by holding the button down again for ten seconds. This
functionality is only available when the display is powered on, displaying an active signal, and the
OSD is not active.
Product support
For additional information on using your monitor, go to http://www.hp.com/support. Select your
country or region, select Troubleshooting, and then enter your model in the search window and click
the Go button.
NOTE: The monitor user guide, reference material, and drivers are available at http://www.hp.com/
support.
If the information provided in the guide does not address your questions, you can contact support. For
U.S. support, go to http://www.hp.com/go/contactHP. For worldwide support, go to
http://welcome.hp.com/country/us/en/wwcontact_us.html.
Here you can:
Chat online with an HP technician
NOTE: When support chat is not available in a particular language, it is available in English.
Find support telephone numbers
Locate an HP service center
Preparing to call technical support
If you cannot solve a problem using the troubleshooting tips in this section, you may need to call
technical support. Have the following information available when you call:
Monitor model number
Monitor serial number
Purchase date on invoice
Conditions under which the problem occurred
Error messages received
Hardware configuration
Name and version of the hardware and software you are using
Button lockouts 29

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Compaq L2206tm and is the answer not in the manual?

HP Compaq L2206tm Specifications

General IconGeneral
3DNo
Pixel pitch0.248 x 0.248 mm
Aspect ratio16:9
Display diagonal21.5 \
Viewing angle, vertical160 °
Contrast ratio (dynamic)1000000:1
Contrast ratio (typical)1000:1
Display number of colors-
Viewing angle, horizontal170 °
Display brightness (typical)220 cd/m²
Supported graphics resolutions1920 x 1080 (HD 1080)
On/off switchYes
USB hub version2.0
HDMI ports quantity0
USB Type-A downstream ports quantity2
LED indicatorsPower
Tilt angle range-5 - 30 °
Panel mounting interface- mm
AC input voltage100 - 240 V
Power consumption (max)39 W
Power consumption (standby)0.5 W
Power consumption (typical)25 W
Product colorBlack
Country of originChina
Operating temperature (T-T)5 - 35 °C
Operating relative humidity (H-H)20 - 80 %
Cables includedAC, Audio (3.5mm), DisplayPort, DVI, USB, VGA
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)228 mm
Height (with stand)445 mm
Weight (with stand)7000 g
Depth (without stand)53.6 mm
Width (without stand)518 mm
Height (without stand)323.1 mm
Weight (without stand)- g
