HP Compaq L2206tm User Manual

Locating the rating labels
The rating labels on the monitor provide the spare part number, product number, and serial number.
You may need these numbers when contacting HP about the monitor model. The rating labels are
located on the rear panel of the monitor display head.
Figure 3-14 Locating the rating labels
Installing a cable lock
You can secure the monitor to a fixed object with an optional cable lock available from HP.
Figure 3-15 Installing a cable lock
16 Chapter 3 Setting up the monitor

HP Compaq L2206tm Specifications

General

3D	No
Pixel pitch	0.248 x 0.248 mm
Aspect ratio	16:9
Display diagonal	21.5 \
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	1000000:1
Contrast ratio (typical)	1000:1
Display number of colors	-
Viewing angle, horizontal	170 °
Display brightness (typical)	220 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
On/off switch	Yes
USB hub version	2.0
HDMI ports quantity	0
USB Type-A downstream ports quantity	2
LED indicators	Power
Tilt angle range	-5 - 30 °
Panel mounting interface	- mm
AC input voltage	100 - 240 V
Power consumption (max)	39 W
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Product color	Black
Country of origin	China
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, Audio (3.5mm), DisplayPort, DVI, USB, VGA

Weight and Dimensions

Depth (with stand)	228 mm
Height (with stand)	445 mm
Weight (with stand)	7000 g
Depth (without stand)	53.6 mm
Width (without stand)	518 mm
Height (without stand)	323.1 mm
Weight (without stand)	- g
