5–14 Maintenance and Service Guide
Removal and Replacement Procedures
2. Loosen the two PM2.0×4.0 screws 1 that secure the
Mini PCI compartment cover to the notebook.
3. Lift the front edge of the Mini PCI compartment cover, and
then swing it back 2.
4. Remove the Mini PCI compartment cover.
✎
Spare part number 371806-001 should be used to replace
the Mini PCI compartment cover.
Removing the Mini PCI Communications Compartment Cover
To Next Page
