Product Description
Maintenance and Service Guide 1–19
5 External monitor port Connects an optional VGA external monitor
or projector.
6 Exhaust vents (2) Provide airflow to cool internal components.
Ä
To prevent overheating, do not obstruct
vents. Do not allow a hard surface, such
as a printer, or a soft surface, such as
pillows, thick rugs or clothing, to block
airflow.
7 Security cable slot Attaches an optional security cable to the
notebook.
8 RJ-11 (modem) jack Connects the modem cable.
9 PC Card slot(s)
(1 or 2)
Support an optional Type I or Type II 32-bit
(CardBus) or 16-bit PC Card.
10 PC Card eject button(s)
(1 or 2)
Eject an optional PC Card from the PC Card
slot.
11 1394 port
(select models only)
Connects an optional 1394a device such
as a scanner, a digital camera, or a digital
camcorder.
12 Audio-in
(microphone) jack
Connects an optional monaural (single
sound channel) microphone.
13 Audio-out
(headphone) jack
Connect optional headphones or powered
stereo speakers. Also connect the audio
function of an audio/video device such as
a television or VCR.
14 Volume up button Increases system volume.
15 Volume down button Decreases system volume.
16 Volume mute button
Mute light
Mutes or restores volume.
On: Volume is muted.
Table 1-5
Rear and Left-Side Components
HP Pavilion ze4900, HP Compaq nx9030, nx9020,
and Compaq Presario 2200
(Continued)
Item Component Function
