1–20 Maintenance and Service Guide
Product Description
The external components on the rear and left side of the
HP Compaq nx9040 notebook are shown below and described
in Table 1-6.
Rear and Left-Side Components - HP Compaq nx9040
Table 1-6
Rear and Left-Side Components
HP Compaq nx9040
Item Component Function
1 Power connector Connects an AC adapter cable.
2 USB connectors (2) Connect optional USB devices.
3 RJ-45 (network) jack Connects an optional network cable.
4 S-Video jack Connects an optional S-Video device, such
as a television, VCR, camcorder, projector,
or video capture card.
5 Parallel port Connects an optional parallel device such as
a printer.
6 Serial port Connects an optional serial device
such as keyboard or mouse.
