Compaq Professional Workstation SP750 Hardware Reference Guide 2-11
Compaq Confidential - Need to Know Required
Writer: Beth Zanca Part Number: 190709-001 File Name: ch2.doc
Last Saved On: 04/12/00 1:02 PM Last Saved By: Lydia Sanchez
1. Turn off the workstation and any external devices, then disconnect
the power cord from the grounded AC outlet.
2. Remove the workstation access panel.
3. Press outward on the two RIMM slot retainer latches.
4. Place the RIMM in the appropriate RIMM slot and ensure that it is
fully inserted and properly seated.
CAUTION: Be sure to follow the correct configuration guidelines
respective to your memory board or your system will not function.
5. Press inward on the two retainer latches to secure the RIMM in the
slot.
Installing a RIMM
6. Reinstall the memory board. See Installing a Memory Board in
this chapter.
7. Replace the workstation access panel.
8. Plug the power cord back into the grounded AC outlet. Reconnect
any external devices.
9. Turn on the workstation.
The workstation should automatically recognize the added memory.
