Screw Listing
Maintenance and Service Guide C–3
Phillips M2.0 × 4.0 Screw Locations
Table C-1
Phillips M2.0 × 4.0 Screw
(Continued)
Color Qty. Length Thread
Head
Width
Silver 9 4.0 mm 2.0 mm 3.8 mm
Where used:
4 screws that secure the display panel to the display bezel
(documented in Section 5.6)
mm
