Removal and Replacement Procedures
Maintenance and Service Guide 5–35
5.8 Fan and Heat Sink
✎
The fan and heat sink are included with the system board;
however, the fan and heat sink can also be ordered separately.
Perform the following steps to remove the fan and heat sink:
1. Prepare the tablet PC for disassembly (refer to Section 5.3,
“Preparing the Tablet PC for Disassembly”).
2. Remove the display panel assembly (refer to Section 5.6,
“Display Panel Assembly”).
3. Remove the system board (refer to Section 5.7, “System
Board”).
Fan and Heat Sink
Spare Part Number Information
Fan
Heat Sink
348342-001
310665-001
348354-001
