HP Compaq tc1100 Maintenance And Service Guide

Removal and Replacement Procedures
Maintenance and Service Guide 5–25
5.7 System Board
Perform the following steps to remove the system board:
1. Prepare the tablet PC for disassembly (refer to Section 5.3,
“Preparing the Tablet PC for Disassembly”).
2. Remove the RTC battery (refer to Section 5.4, “Real Time
Clock Battery”).
3. Remove the hard drive (refer to Section 5.5, “Hard Drive”).
4. Remove the display panel assembly (refer to Section 5.6,
“Display Panel Assembly”).
System Board
Spare Part Number Information
System board with fan and heat sink
Mobile Intel Celeron, 800-MHz
Mobile Interl Celeron, 900-MHz
Intel Pentium M, 1.0-GHz
Intel Pentium M, 1.1-GHz
348331-001
374024-001
348332-001
374023-001
