C–8 Maintenance and Service Guide
Screw Listing
Phillips M2.0 × 5.0 Screw Locations
Table C-6
Phillips M2.0 × 5.0 Screw
Color Qty. Length Thread
Head
Width
Yellow 3 5.0 mm 4.0 mm 3.8 mm
Where used:
3 screws that secure the display panel bracket to the display panel assembly
(documented in Section 5.6)
mm
